Oil Free Scroll Compressor

Working Pressure :
8-10[ bar ]
116-145[ psig ]
Free Air Delivery :
9-172[ cfm ]
0.24-4.8[ m³/min ]
Working Power :
2.2-44[ kw ]
3-60[ hp ]

Airstone scroll compressors provide 100% oil free air for these critical applications. Oil free compressors help eliminate potential contamination as no oil or lubricant is introduced into the air compression process.

Model Number	HYW4	HYW4H	HYW8	HYW8H	HYW11	HYW11H	HYW15	HYW15H	HYW22	HYW22H	HYW30	HYW30H
Rated Power	3.7		7.5		11		15		22		30
Airend Number	1		2		3		4		6		8
Max capacity(M3/H)	24	21.3	48	42.6	72	63	96	84	144	126	192	168
Work Pressure(Bar)	8.0	10.0	8.0	10.0	8.0	10.0	8.0	10.0	8.0	10.0	8.0	10.0
Rated Voltage(V/Hz)	380/50
Motor Speed	2870
Working Ambient Temperature	-20 to 40 ℃（Remarks: Ambient temperature <0℃ requires auxiliary heat preservation）
