Suitable for PET bottle blowing,leak detection,pressure testing and other industries！

Through various occasions long-term operation and test:Higher reliability (24 hours non-stop running),longer life,lower noise,less vibration,lower exhaust temperature,more fuel-efficient,is designed for high pressure operation in special series products.The main performance indexes reach or exceed the international advanced level of similar products.

* Valve disc:Made of Swedish stainless steel strip.
* Piston ring:Japan‘s Riken ring,single casting chrome-plated ring,3 times longer life.
* Piston:The booster piston uses a heavy-duty cast iron piston.
* Connecting rod:using connecting rod with needle bearing.
* Crankshaft bearing:Heavy-duty,long-life,low-noise bearings.
*  Main engine wheel: iron fan and main engine wheek undergo strict dynamic balance to reduce vibration.
* Pressure controller:world famous brand.
* Cooling and filtering: The first to second stage is cooled and filtered with high efficiency.
* Sewage: using automatic,electronic sewage valve (optional)

Model Number	Capacity(m³/min)	Pressure(MPa)	Horsepower (KW)	Speed   (r/min)	Size(mm)	Weight (KG)	Compression stage
ASH-0.6/30	0.6	3.0	7.5-2	780	1100*530*1020	290	Double stage
ASH-1.0/30	1.0	3.0	11-4	750	1150*800*1000	440	Double stage
ASH-1.2/30	1.2	3.0	15-4	780	1200*850*1150	480	Double stage
ASH-1.6/30	1.6	3.0	18.5-4	800	1350*850*1040	500	Double stage
ASH-2.0/30	2.0	3.0	2*11-4	800	1800*1100*1200	800	Double stage
